Full Disk Access

Full Disk Access (Allows the application access to all protected files, including system administration files) is need for an app to function correctly on macOS. How can that be fixed with an mobileconfig profile and send it out to all macOS clients using MDM.

Note! Microsoft Defender.app is only used as an example.

Codesign

First lets find the identifier, open Terminal and type the command and path to the application to get it.

1. Open Terminal
2. Type:

codesign -dr - "/Applications/Microsoft Defender.app"

output:

• Executable=/Applications/Microsoft Defender.app/Contents/MacOS/wdavdaemon
• designated => identifier “com.microsoft.wdav” and anchor apple generic and certificate 1[field.1.2.840.113635.100.6.2.6] /* exists / and certificate leaf[field.1.2.840.113635.100.6.1.13] / exists */ and certificate leaf[subject.OU] = UBF8T346G9

Help for the command:

• codesign → A macOS command-line tool for managing code signatures.
• -dr - →
  • -d → Displays information about the app’s signature.
  • -r - → Displays the designated requirement (a policy that defines how the app’s signature is validated).
• /Applications/Microsoft Defender.app" → The path to the Microsoft Defender app (if installed).

Check if application has Full Disk Access

To check if an application already have Full Disk Access or if it is working after Full Disk Access has been applied run the following command. If there is more that one result listed some searching for the application may be needed in the list. (Sometimes Full Disk Access still work even though it does not show here or can be seen in the GUI under System Settings)

1. Open Terminal
2. Type:

sudo sqlite3 "/Library/Application Support/com.apple.TCC/TCC.db" "SELECT * FROM access WHERE service='kTCCServiceSystemPolicyAllFiles';"

output:

• kTCCServiceSystemPolicyAllFiles|com.microsoft.wdav|0|1|1|2024-02-23 10:30:45|2024-02-22 14:15:12|UNUSED|UNUSED|1234567890

Understanding the Output

Each field represents different values of the application.

Defender had Full Disk Access to the system on this mac, it could be seen in the output that it was a 1 for the Allowed.

Create a mobileconfig file

Create the mobileconfig file that can be used to send out from MDM to all other macOS clients.

To create the mobileconfig file lets use iMazing.

1. Download iMazing app from Apple App Store iMazing
2. Open the app and search for Privacy Preferences Policy Control and add that.
3. Under Privacy Preferences Policy Control scroll down to Full Disk Access section.
4. Fill in
   • Identifier: com.microsoft.defender
   • Identify Type: Bundle ID
   • Code Requirement: identifier “com.microsoft.wdav” and anchor apple generic and certificate 1[field.1.2.840.113635.100.6.2.6] /* exists / and certificate leaf[field.1.2.840.113635.100.6.1.13] / exists */ and certificate leaf[subject.OU] = UBF8T346G9
   • Static Code: Optional
   • Authorized: No Value
   • Allowed: 1
   • Comment: Optional

There is a possibility to use Path instead of “Bundle ID” as “Identify Type” that could be when the App Has No Bundle ID. Or check in this table below.

But this is a Standard installed app so we use the above this is only for demonstration.

If using Path it should look like this:

• Identifier: /Applications/Microsoft Defender.app/Contents/MacOS/wdavdaemon
• Identify type: Path
• Code Requirement: identifier “com.microsoft.wdav” and anchor apple generic and certificate 1[field.1.2.840.113635.100.6.2.6] /* exists / and certificate leaf[field.1.2.840.113635.100.6.1.13] / exists */ and certificate leaf[subject.OU] = UBF8T346G9
• Static Code: Optional
• Authorized: No Value
• Allowed: 1
• Comment: Optional

Don’t forget to update the General section in Imazing and save the profile.

Example from the saved mobileconfig file.

            <dict>
                <key>SystemPolicyAllFiles</key>
                <array>
                    <dict>
                        <key>Allowed</key>
                        <true/>
                        <key>CodeRequirement</key>
                        <string>identifier "com.microsoft.wdav" and anchor apple generic and certificate 1[field.1.2.840.113635.100.6.2.6] /* exists */ and certificate leaf[field.1.2.840.113635.100.6.1.13] /* exists */ and certificate leaf[subject.OU] = UBF8T346G9</string>
                        <key>Comment</key>
                        <string></string>
                        <key>Identifier</key>
                        <string>com.microsoft.wdav</string>
                        <key>IdentifierType</key>
                        <string>bundleID</string>
                    </dict>
                </array>
            </dict>

Deploy it via MDM as a Device Channel deployment.

Don’t want to it manually a great tool to grant Full Disk Access is: Privacy Preferences Policy Control (PPPC) Utility
